Drying Oven with Hot Air Circulation
1
1
1
1
1

Drying Oven with Hot Air Circulation

  • Model: DHX-10
  • Power Source: Electricity / Diesel / Steam Gas
  • Power: 4.5KW
  • Temperature Setting Range: 15-80℃
  • Tray Dimensions: 800×600×50 mm
  • Tray Quantity: 10
  • Drying Chamber Dimensions: 1200×1100×1200 mm
  • Capacity: 100-150 kg
  • Email: info@hadofmachinery.com
  • WhatsApp: +8615239453015
  • Tel: +86 371-8658281
Inquiry WhatsApp

Production Process

Main Equipment

Parameter Table

Model DHX-10 DHX-20 DHX-40 DHX-80
Power (kw) 4.5 6.5 12.5 19
Temperature Adjustment Range 15-80°C
Tray Dimensions (mm) 800*600*50
Number of Trays 10 20 40 80
Drying Chamber Dimensions (mm) 1200*1100*1200 1200*1100*2000 1800*1200*2000 2200*1600*2000
Capacity (kg) 100-150 150-200 200-300 300-400

Product Features

The entire casing adopts a fully enclosed structure, allowing for efficient utilization of internally circulated hot air and achieving significant energy savings.

Equipped with a high-temperature-resistant, unibody long-axis fan, it ensures forced circulation of hot air, significantly reducing heat loss during the circulation process.

The drying carts and trays meet industry-standard specifications, offering multiple tray styles that are suitable for different industries and fully interchangeable.

The equipment features low operating noise, stable performance, automatic temperature control, and easy installation and maintenance. Versatile in use, it can dry a wide variety of materials, making it a universal drying system.
