Drying Room

  • Model: HDF-1.5P
  • Power Source: Electricity / Diesel / Steam Gas
  • Power: 1.98KW
  • Temperature Regulation Range: 15-80℃
  • Tray Dimensions: 800*600*20 mm
  • Number of Trays: 18
  • Drying Chamber Dimensions: 1500*700*1940 mm
  • Capacity: 150-200 kg
  • Email: info@hadofmachinery.com
  • WhatsApp: +8615239453015
  • Tel: +86 371-8658281
Inquiry WhatsApp

Production Process

Main Equipment

Parameter Table

Model HDF-1.5P HDF-3P HDF-5P HDF-7P HDF-15P HDF-25P
Energy Source air energy
Power (kw) 1.98 3.3 3.5 6.2 14.5 16.6
Temperature Adjustment Range 15-80°C
Tray Dimensions (Mm) 800*600*20 800*600*20 800*600*50 800*600*50 800*600*50 800*600*50
Number of Trays 18 36 120 180-270 270-360-450 450-540-600
Drying Chamber Dimensions (Mm) 1500×700×1940 1700×860×2150 4000×2050×2500 6000×2050×2700 6000×3000×2700 9000×3000×2700
Capacity (kg) 150-200 200-300 500-600 600-750 1000-1500 2000-2500

Product Features

The hot air circulation system ensures even air distribution, high drying efficiency, and precise temperature control, adapting to a variety of drying needs.

Compatible with multiple sectors (industrial, food, scientific, etc.), it is capable of drying electronic components, food, and other materials.

The intelligent control system offers easy operation: parameter setting and automatic operation. Its structure facilitates cleaning, maintenance, and component replacement.

Optimized thermal insulation reduces energy consumption. Equipped with safety devices such as over-temperature alarms and leakage current protection, ensuring safe operation.
