Pre-Packed Granule Packaging Machine Parameters
| Model | HDF-GD8-230 | HDF-GD8-260 | HDF-GD8-300 |
| Pre-Made Bag Size | A：90-230 mm L：90-350 mm | A：140-260 mm L：100-350 mm | A：200-300 mm L：150-400 mm |
| Packaging Speed | 25-50 bags/min | 15-50 bags/min | 10-35 bags/min |
| Filling Range | 10 g – 500 g | 10 g – 1000 g | 10 g -2 500 g |
| Air Consumption | ≤0.8 m³/min | ||
| Voltage / Power | 380 V / 2500 W | ||
| 8-Station Work Process | 1. Bag feeding / 2. Coding / 3. Bag top opening / 4. Material filling / 5. Reservation / 6. Reservation / 7. Heat sealing / 8. Forming and output | ||
| Optional Equipment | Horizontal bag loading, zipper opening, bottom bag opening, vibration, dust removal, zipper closing, nitrogen filling, etc. | ||
Roll Film Bag Making And Packaging Machine Parameters
| Model | HDF-B420-520KC | |
| Maximum Width of Roll Film | 420MM/520MM | |
| Bag Dimensions | W80-200MM L60-300MM | W80-250MM L80-390MM |
| Packaging Weight Range | 10g-500g | 10g-1000g |
| Packaging Speed | 5-30 bags/min | 5-25 bags/min |
| Voltage/Power | 220V/2.4KW | 220V/2.4KW |
| Gas Consumption | 0.6m3/min | 0.6m3/min |
| Packaging Material/Thickness | opp/cpp/ce mst/pet/pe/0.04-0.08M | |
Made of SUS304 food-grade stainless steel, it meets sanitary standards, is corrosion-resistant, easy to clean, and robust.
Hadof offers a comprehensive service guarantee, from installation and commissioning to after-sales maintenance, with expert engineers available to answer questions.
Equipped with an intuitive control panel, it provides easy and intelligent operation, supporting parameter customization.
Rich Experience
In Export
Oversea Installation
Service
Environmentally
Friendly
High Quality
Assurance
Free Designing
Scheme
Customer Oriented
Service
×
With high-quality products, professional services Hadof helps factory construction and grow together with customers
