Vacuum Freeze Dryer

  • Model: HDF-30
  • Total Effective Load Area: 3 m²
  • Heating Method: Thermal Transfer/Contact Heat
  • Cold Trap Type: Back Trap
  • Maximum Load Capacity per Compartment: 0.24 m³/cycle
  • Standard Feeding Capacity: 30 kg/batch
  • Freezing Time: 4-6 h
  • General Drying Time: 12-35 h
  • Email: info@hadofmachinery.com
  • WhatsApp: +8615239453015
  • Tel: +86 371-8658281
Inquiry WhatsApp

Production Process

Main Equipment

Parameter Table

Model HDF-30 HDF-50 HDF-100 HDF-200
Total Effective Loading Area (m²) 3 6 10 20
Heating Method Thermal Heat Transfer/Contact
Type Of Cold Trap Rear Trap
Maximum Load Capacity Per Compartment (m³/Cycle) 0.24 0.28 0.3 0.63
Standard Feed Capacity (Kg/Batch) 30 50 100 200
Freezing Time (h) 4~6 4~6 4~6 12
General Drying Time (h) 12~35

Product Features

The freeze-drying process is carried out at low temperatures, making it particularly suitable for many thermosensitive substances.

Drying occurs with the material in a frozen state, so the volume remains virtually unchanged and the original structure is preserved, preventing concentration phenomena.

Since drying is carried out under vacuum conditions, the oxygen content is extremely low, which protects substances prone to oxidation.

The drying process removes between 95% and more than 99% of the moisture content, allowing for prolonged storage without deterioration of the freeze-dried product.
